Dimensions
L 2808mm x W 5680mm x H 1885mm
Cutting Area
1600mm x 1200mm
Collection Area
1600mm x 1200mm
Perfection in every detail
Automatic Feeding
8-layer automatic feeding grid that allows continuous cutting, contributing to the improvement of the continuity and stability of the production line, reducing waiting time.
Dual head system
Dual-head asynchronous system Suitable for various cuts of shoe uppers, the perfect dual-head asynchronous motion control systems greatly improve the processing speed and quality.
Positioning of the red light
Ensures accurate and error-free cutting during the cutting machine process with oscillating blades.
Pneumatic oscillating cutting
Pneumatic oscillating cutting device. It is power, can meet the need of cutting thick materials.
Electric oscillating cutter
Multiple blades to meet different needs.
Punching module
It can be used for different punching sizes.
Technical parameters
Model
Processing area
1600 mm x 1250mm
Max cutting speed
800 mm/s
Acceleration
5000 mm/s
Absorption power
20 m/s
Weight
2500 kg
Real power
11500 W
Maximum blower power
9000 W x 1
Supported formats
Windows 7/8/10, AI, PLT, DXF, DST, DSB
Feeding
380 VAC/32A 50Hz or 60Hz
